New Headline/cyclone motor mount bracket

Postby AFT » Sun Feb 12, 2012 6:47 am

Hi to all

We have just made and released photos of our next batch of motor mount brackets, they will suit just about any down tube diameter and profile . Also we have left some room if you would like to go larger then 48 Teeth chain rings between the motor and freewheel. Their is enough slack in the motor mount slots to adjust the chain tension without the need for a chain tensioner.

Any other technical question about the brackets please ask


Jim

AFT

aft_ebike@hotmail.com
Attachments
Hduty bracket Chain side small.jpg
Hduty bracket Non Crank small.jpg
APPLIED FUTURE TECHNOLOGIES
Specialising in high performance and high efficiency custom electric mid drive conversions kits.

Website : Af-tech.com.au
Email : Aft_ebike@hotmail.com

Since 2009 we have reached 8000km of real world reliability and efficiency improvement testing on our mid drive kit and testing is an ongoing process ….

Our Ethos "Proven design through long term real world reliability testing"
AFT
1 mW
1 mW

Posts: 14
Joined: Tue Jun 21, 2011 1:50 am

Re: New Headline/cyclone motor mount bracket

Postby darkone040 » Mon Feb 27, 2012 8:24 am

i have had endless troubles keeping my cyclone motor in alignment with the chain wheel and this would be perfect..
oh i just noticed the second chain in your picture, would this work with a single chain wheel setup.. i guess i would need a tensioner then..
how much would this cost me, would probably need all the nuts and bolts too?.. and cost if i need the 48t triple chain wheel, and extra chain?

how come tensioner isn't a word, its got a red squiggly line under it?
less weight means more fast
darkone040
10 W
10 W

Posts: 93
Joined: Sun Mar 06, 2011 3:21 pm
Location: adelaide, australia

Re: New Headline/cyclone motor mount bracket

Postby AFT » Wed Feb 29, 2012 6:05 am

Hi Sorry about the delay , just saw this post.

The bracket suits the dual or triple freewheel, not the single chainwheel, so yes you need 2 chains as well.

We have also noticed that their is a significant efficiency improvement when not having to run a chain tensioner. We have also noticed an efficiency improvement in using our oil conversion kit for the gearbox, which we will be releasing soon for high power and high mileage motors.

Grease is not suited to high rpms and also has high parasitic losses compared to oil , normally for high power motors this is not much of an issue, but when you have limited motor power and battery capacity, the increase in efficiency is actually quite significant.


We have not exactly quantified this improvement yet, the initial testing is showing some good gains, but we will try and get some exact numbers on these efficiency improvements soon.

Did you just contact us on ebay also ? if so i have answered some of your questions their.

If you have any other pricing questions email us on aft_ebike@hotmail.com for the latest pricing.

Jim

AFT
APPLIED FUTURE TECHNOLOGIES
Specialising in high performance and high efficiency custom electric mid drive conversions kits.

Website : Af-tech.com.au
Email : Aft_ebike@hotmail.com

Since 2009 we have reached 8000km of real world reliability and efficiency improvement testing on our mid drive kit and testing is an ongoing process ….

Our Ethos "Proven design through long term real world reliability testing"
AFT
1 mW
1 mW

Posts: 14
Joined: Tue Jun 21, 2011 1:50 am

Re: New Headline/cyclone motor mount bracket

Postby darkone040 » Fri Mar 02, 2012 10:50 am

yeah that was me that asked on ebay, but i cant for the life of me find your response..
please get back to me with a price, cheers adrian
less weight means more fast
darkone040
10 W
10 W

Posts: 93
Joined: Sun Mar 06, 2011 3:21 pm
Location: adelaide, australia

Re: New Headline/cyclone motor mount bracket

Postby AFT » Fri Mar 02, 2012 3:44 pm

PM sent
APPLIED FUTURE TECHNOLOGIES
Specialising in high performance and high efficiency custom electric mid drive conversions kits.

Website : Af-tech.com.au
Email : Aft_ebike@hotmail.com

Since 2009 we have reached 8000km of real world reliability and efficiency improvement testing on our mid drive kit and testing is an ongoing process ….

Our Ethos "Proven design through long term real world reliability testing"
AFT
1 mW
1 mW

Posts: 14
Joined: Tue Jun 21, 2011 1:50 am

Re: New Headline/cyclone motor mount bracket

Postby AFT » Sat Mar 03, 2012 6:20 am

Darkone

I sent another PM tonight with some more details but it seems to be stuck in my outbox ? I sent an email to an administrator but that is also stuck in my outbox !

Any moderators that can access my account to see why they are stuck their and not in the sent items ?

Jim

AFT
APPLIED FUTURE TECHNOLOGIES
Specialising in high performance and high efficiency custom electric mid drive conversions kits.

Website : Af-tech.com.au
Email : Aft_ebike@hotmail.com

Since 2009 we have reached 8000km of real world reliability and efficiency improvement testing on our mid drive kit and testing is an ongoing process ….

Our Ethos "Proven design through long term real world reliability testing"
AFT
1 mW
1 mW

Posts: 14
Joined: Tue Jun 21, 2011 1:50 am

Re: New Headline/cyclone motor mount bracket

Postby AFT » Sat Jul 21, 2012 5:38 am

We have a some more info on the brackets on our website:

http://www.af-tech.com.au/Products_Ebikes.html

Shortly we will be releasing a new version of the bracket from aluminium with cross bracing to easily handle more then 1.2kw of motor power. ( Confirm your interest email us at aft_ebike@hotmail.com )

Also the new version will have some added features:

- Lighter weight and more torsional stifness
- Access to the oil breather hole when running oil vs grease i.e motor and gearbox does not have to be removed to drain/fill the oil.
- Room for mounting a crank sensor on the drive side.
- More offset adjustment to allow easier tension adjustement so no need for a chain tensioner, which gives an improvment in drivetrain efficiency.

We will be doing some testing and collecting data to show the improvements in efficiency when running our oil in the gearbox vs grease and also when using our bracket and hence without a chain tensioner.

Jim

AFT
APPLIED FUTURE TECHNOLOGIES
Specialising in high performance and high efficiency custom electric mid drive conversions kits.

Website : Af-tech.com.au
Email : Aft_ebike@hotmail.com

Since 2009 we have reached 8000km of real world reliability and efficiency improvement testing on our mid drive kit and testing is an ongoing process ….

Our Ethos "Proven design through long term real world reliability testing"
AFT
1 mW
1 mW

Posts: 14
Joined: Tue Jun 21, 2011 1:50 am

Re: New Headline/cyclone motor mount bracket

Postby AFT » Wed Aug 15, 2012 11:52 pm

Due to poppular requests, we will be releasing our new 6mm laser cut cross braced bracket kit in Steel as well and we will also be offering it on a new product promotion. This bracket is ideal for 960w and above motors to the high torque.

Also to lower costs the bracket will be sold in raw steel finish so you can apply your own paint finish and colours to match your bicycle.

This mounting kit will come with all the hardware to mount a cyclone/headline motor to nearly any bicycle, the strongest and most reliable way possible, as it 's located around the Bottom bracket, so their can be no slippage or movement over time.

Also our mounting system has enough adjustment that no chain tensioner is required, this only possible with a very stiff mounting system as normal mounting systems can flex under load and cause chain derailments. However some crank arms/freewheel have a lot of runout and cannot be tensioned succesfuly and a chain tensioner maybe needed in these situations unless crank freewheel mounting is machined correctly.

If you are purchasing a kit from us the new bracket kit upgrade price will be $99 AUD, if you are not purchasing a kit from us the total price is $119 AUD + postage excluding the chain tensioner.

After the new product promotion the regular price will be Kit upgrade$119 +$39 for non kit upgrade price.

When ordering please advise us of the circumference of your down tube in the locations specified in the attached drawings so we can send you the correct clamps.



http://www.af-tech.com.au/Products_Ebikes.html

Contact us on Aft_ebike@hotmail.com

Jim

AFT
Attachments
6mm cross bracing.jpg
AFT steel bracket kit.jpg
AFT steel bracket kit.jpg (26.21 KiB) Viewed 1327 times
AFT Hduty 6mm bracket circumference points measurements.jpg
AFT Hduty 6mm bracket circumference points measurements.jpg (33.37 KiB) Viewed 1327 times
APPLIED FUTURE TECHNOLOGIES
Specialising in high performance and high efficiency custom electric mid drive conversions kits.

Website : Af-tech.com.au
Email : Aft_ebike@hotmail.com

Since 2009 we have reached 8000km of real world reliability and efficiency improvement testing on our mid drive kit and testing is an ongoing process ….

Our Ethos "Proven design through long term real world reliability testing"
AFT
1 mW
1 mW

Posts: 14
Joined: Tue Jun 21, 2011 1:50 am

Re: New Headline/cyclone motor mount bracket

Postby jlustig83 » Wed Jul 10, 2013 7:51 am

where did you find those braket mount clamps? they would be good for mounting a batterybox
jlustig83
100 W
100 W

Posts: 126
Joined: Fri Nov 28, 2008 6:29 pm

Re: New Headline/cyclone motor mount bracket

Postby spinningmagnets » Wed Jul 10, 2013 8:40 am

McMaster-Carr http://www.mcmaster.com/#
"T-bolt hose and tube clamps", listed under "bolt hose clamps", under "hose and tube clamps", under "Pipe, Tubing, Hose & Fittings"

http://www.mcmaster.com/#standard-hose-clamps/=nk6vus
