Batteries vs Cold ☃

Post by DrkAngel » Dec 16, 2010 1:20 pm

All forms of batteries seemed to be adversely affected by Cold!

Very noticeable, especially on my various ebikes, was that, cold greatly reduced the rate of output, as well as the capacity of various types of batteries.

This degradation is common to both Li-ion, as well as SLA batteries. Based on complaints, from others, LiFePO4, Li-po, Nimh etc. seem to suffer similarly.

The "rate of output" is often designated as the "C" rating. For example a 30ah battery, capable of a 30 amp output, would have a rating of 1C, a high performance RC car battery, (Li-po), might be a 5ah 20C rated, thus capable of a 100amp output, of course it would empty, very quickly!

Sub freezing temperature might cut the C rating, as well as the overall capacity by 50%. 0 degrees Fahrenheit degrades considerably more!

In my experience, most of this degradation is due to the battery temperature, though the motor and drivetrain also contribute, somewhat.

My recommendation is that the battery should be kept warm.

Easiest would be the use of a water heater blanket, to maintain ambient heat.

Stage 2 would be the application of a thermostatically controlled heat tape, such as is used to prevent pipes from freezing. While charging, the heat tape might not engage, but will maintain temperature after charge completes. It might even be efficient to self heat battery if left for prolonged period in the cold, several hours?

Caution! Some batteries require active ventilation, (mainly to prevent over heating), be sure not to cover fans, ventilation grills, etc!
Last edited by DrkAngel on Jan 08, 2016 10:48 am, edited 2 times in total.
A little learning is a dangerous thing;
Drink deep, or taste not the Pierian spring:
There, shallow draughts intoxicate the brain,
And drinking largely, sobers us again.

I enjoy enlightening ... and enlivening the spirit of the innovators.

New & Improved - Acronym Definitions

Index - Homemade Battery Packs - Updated - November 2015

EBike Toolbox - Bargains! $

Endless Sphere Wiki

User avatar
DrkAngel
10 GW
10 GW
Posts: 4462
Joined: Dec 15, 2010 11:14 am
Location: Upstate-Western-Southern Tier NY. USA

Re: Batteries vs Cold

Post by DrkAngel » Dec 17, 2010 9:38 am

My main transports are EZip "Trailz" electric assist bikes. They come stock with 10AH SLA batteries, which are very poor, to begin with, but suffer mightily when cold, and forced to push through snow, or slush.
Actual usable output is merely 6AH, but when cold, possibly only 3ah. Unfortunately, when pushed through a cold, geared, brush motor, actual output power might be less than 2AH. (The AH rating of SLA batteries is typically determined by a slow drain, over a 20 hr period, with a more typical 1 hr drain, output is approximately only 60% of "rated".)

Why even bother?

I bought my first about 3 years ago, when gas passed $4/gallon.
A complete electric vehicle for less than $400, which almost covered my, run around town, "errand", gas cost, for that summer!

$348 w/shipping included, available, right now from Amazon.com and Walmart.com!

Of course I had to upgrade capability and capacity! Speed was increased from OEM 15mph to, variously, 20, 22, 24, and 27mph, (motor alone speed), using various methods. "Motor only" range was about 8 miles, increased to, 40 miles @ 16mph, (30 miles @ 20 mph). Of course I upgraded pedal assist capability to allow much better range, and higher speed.

However, I digress.
My main point is that I built Li-ion battery packs, from used notebook batteries! EZip OEM batteries are 24v SLA batteries with a usable 6AH. I built 25.9v 31.2AH packs, as well as 37v 20.8AH. Approximately 5X the usable output, at about 60% of the weight. For the Winter, I place the packs in insulated, fabric "lunch bags" with cardboard inserts, allowing for insertion into the OEM battery racks. The bottom power contacts were impractical, so I converted to AC power cord connectors. So, battery is kept warm, and dry, by insulated bag. Removal to a warm location is a simple, unplug and lift, by built in lunch bag, handle. Bag is secured by a cable lock that happened to fit perfectly around rear rack, and over top of pack.

Yes, I do ride in Winter! Studded tires are essential. Visibility and proper attire, are important factors in being, "safe & warm".

This Winters project, will be, a Schwinn 3-wheeler conversion, to electric assist. Canopy and windshield are definite possibilities.

I am making progress towards an eCar!

Stories of my upgrades and adventures will be posted in the ebike section.

I will post notification here, when completed, (I have many pictures and articles posted on other sites, that use an incompatible format, proper translation might take some little work).

Image EZIP ENGINEERING 101 Image
Last edited by DrkAngel on Dec 18, 2010 9:15 am, edited 2 times in total.
A little learning is a dangerous thing;
Drink deep, or taste not the Pierian spring:
There, shallow draughts intoxicate the brain,
And drinking largely, sobers us again.

I enjoy enlightening ... and enlivening the spirit of the innovators.

New & Improved - Acronym Definitions

Index - Homemade Battery Packs - Updated - November 2015

EBike Toolbox - Bargains! $

Endless Sphere Wiki

User avatar
Ypedal
100 GW
100 GW
Posts: 13879
Joined: Dec 27, 2006 12:55 pm
Location: Moncton NB, Canada
Contact:

Re: Batteries vs Cold

Post by Ypedal » Dec 17, 2010 9:47 am

ES site status page:
http://www.ypedal.com/ES/ES.htm
----------------
http://www.ypedal.com

User avatar
ET4041
1 mW
1 mW
Posts: 19
Joined: May 08, 2010 10:11 pm
Location: Toronto Ontario

Re: Batteries vs Cold

Post by ET4041 » Dec 17, 2010 7:29 pm

I ride my bike everyday to work so far this winter. It's been around -5C to -10C with some days down to -14C here in Toronto. This is before the wind chill. I just take the battery inside, let it sit for 1/2 hour to warm up, then charge. On the bike, the battery is in a Topeak rack bag with lots of padding so there is some insulation. My ride each way to work is about 18 km which takes about 30-40 minutes. The voltage is a little lower than in summer (maybe .5 to 1 volts lower on my 10 Ah, 50V Lifepo4 pack), and there might be slightly less capacity although I don't know for sure because I don't use more than 80% of capacity.

My colleagues probably think I am crazy for bicycling all winter, but it is quite addictive. Going through the snow just makes it more fun - especially the fresh powdery stuff. It would be a tough slog without my trusty hub motor - a BMC600W-T from Ilia. I haven't got any studded tires yet, but I have one on order (for the front). The biggest problem is probably the rusting of the chain and drivetrain as the bike cage at work is in a heated space.

User avatar
Lock
10 GW
10 GW
Posts: 4621
Joined: May 24, 2007 5:46 pm
Location: Toronto Harbour
Contact:

Re: Batteries vs Cold

Post by Lock » Dec 17, 2010 9:23 pm

Check out the specs on the Toshiba SCiB lithium-titanate cells:
http://www.toshiba.com/ind/data/tag_fil ... e_5383.pdf

80% capacity at minus 30 Celsius... not too shabby. Honda is using these in their new EV-neo scooter:
http://world.honda.com/news/2010/2101216EV-neo/

tks
LocK
If you like this message feel free to donate BeerCoins (BTC) to:
1LxAXWmbjY6SeMf8r9HHhSKt6pWyPvWg6L

Toronto Electric Riders Association:
http://www.ebikeriders.com/
Canada, eh?

User avatar
DrkAngel
10 GW
10 GW
Posts: 4462
Joined: Dec 15, 2010 11:14 am
Location: Upstate-Western-Southern Tier NY. USA

Re: Batteries vs Cold

Post by DrkAngel » Dec 18, 2010 10:10 am

Link to some of my early EZip Reports:
https://endless-sphere.com/forums/v ... =3&t=23676

Image EZIP ENGINEERING 101 Image
A little learning is a dangerous thing;
Drink deep, or taste not the Pierian spring:
There, shallow draughts intoxicate the brain,
And drinking largely, sobers us again.

I enjoy enlightening ... and enlivening the spirit of the innovators.

New & Improved - Acronym Definitions

Index - Homemade Battery Packs - Updated - November 2015

EBike Toolbox - Bargains! $

Endless Sphere Wiki

ev_nred
100 W
100 W
Posts: 133
Joined: Mar 26, 2010 5:47 pm

Re: Batteries vs Cold

Post by ev_nred » Jan 06, 2011 10:11 pm

why not make some type of heater form the batteries or charge at low current while u park to keep them got

User avatar
wojtek
100 kW
100 kW
Posts: 1361
Joined: Nov 29, 2009 3:52 pm
Location: Luxembourg
Contact:

Re: Batteries vs Cold

Post by wojtek » Jan 07, 2011 4:17 am

Lock wrote:Check out the specs on the Toshiba SCiB lithium-titanate cells:
http://www.toshiba.com/ind/data/tag_fil ... e_5383.pdf

80% capacity at minus 30 Celsius... not too shabby. Honda is using these in their new EV-neo scooter:
http://world.honda.com/news/2010/2101216EV-neo/

tks
LocK

the cell specs look impressive! 7000 cycles at speed charging above all!!!

But they are quite heavy comparing to Lipos.. 2.4V 4.2ah at 155g. That would make a 48v21ah cell weight 15.5kg!
WIRES AND CONNECTORS
https://endless-sphere.com/forums/vi ... 31&t=30176
https://endless-sphere.com/forums/viewto ... 31&t=32244

KMX Cobra with Xlyte 5403
Go-One Evo with Cromotor
BATMOBILE - Astro 3220 / Nuvinci in progress
Giant CRS Alliance - yes, just pushbike! frock you..
3Element Espire - SOLD
Custom built Specialized BigHit with BBS02 - SOLD
Velokraft e-VK3 SOLD
Steintrike Mungo Sport HS3540-SOLD
Scorpion FS HS3540-SOLD
Kona Dawg BMC v2-SOLD

ev_nred
100 W
100 W
Posts: 133
Joined: Mar 26, 2010 5:47 pm

Re: Batteries vs Cold

Post by ev_nred » Jan 08, 2011 5:51 pm

I have an idea (this migth get ugly lol :mrgreen:) have an of u every seen one of those old heated blankets that plug in to the wall? well why not make a mini version of that and dump it in to a battery bock have a 3s battery connect to an inverter to provide the current for the 'blanket'
is this a stupid idea? Could it work?
thanks,
Jacob R

User avatar
Ypedal
100 GW
100 GW
Posts: 13879
Joined: Dec 27, 2006 12:55 pm
Location: Moncton NB, Canada
Contact:

Re: Batteries vs Cold

Post by Ypedal » Jan 08, 2011 6:11 pm

ES site status page:
http://www.ypedal.com/ES/ES.htm
----------------
http://www.ypedal.com

trappermike
100 W
100 W
Posts: 172
Joined: Aug 07, 2008 3:11 pm
Location: British Columbia,Canada

Re: Batteries vs Cold

Post by trappermike » Jan 18, 2011 11:41 am

There's a good thread on this subject under Battery Technology.
Ni-Cd batteries survive cold temps. well without heat but not much appeal to mast folks.

gge5
1 W
1 W
Posts: 57
Joined: Jul 29, 2010 10:20 am

Re: Batteries vs Cold

Post by gge5 » Jan 25, 2011 11:32 am

From personal experience, cold cells definitely affect energy output. Normally my 24 x 40Ah Thundersky pack can get my motorcycle up above 60MPH, but last week it was 39 Fahrenheit and I couldn't push it faster than 47MPH. I was concerned it might be the new controller I put in last month, but yesterday it was sunny and it reached full speed.

User avatar
DrkAngel
10 GW
10 GW
Posts: 4462
Joined: Dec 15, 2010 11:14 am
Location: Upstate-Western-Southern Tier NY. USA

Re: Batteries vs Cold

Post by DrkAngel » Feb 20, 2011 5:17 pm

Over the Winter I have carefully measured voltages at lower temperatures, it seems the capacity is not affected so much as the "C" rating, the output "rate". Under drain, the battery seems empty, but after slight delay battery regains substantial voltage.

Li-ion 18650 notebook scavenged cells will sustain, a prolonged, 1C output at 70*, at 30* the output is closer to 1/2 C. Exceeding the "sustainable output" produces excess drain. This excess drain produces a voltage drop, which is perceived as a drained battery condition.

1C = drain rate equal to ah capacity (2600mah capable of 2.6amp sustained output)
* = degrees F
Last edited by DrkAngel on Dec 05, 2016 1:03 pm, edited 2 times in total.
A little learning is a dangerous thing;
Drink deep, or taste not the Pierian spring:
There, shallow draughts intoxicate the brain,
And drinking largely, sobers us again.

I enjoy enlightening ... and enlivening the spirit of the innovators.

New & Improved - Acronym Definitions

Index - Homemade Battery Packs - Updated - November 2015

EBike Toolbox - Bargains! $

Endless Sphere Wiki

User avatar
Lock
10 GW
10 GW
Posts: 4621
Joined: May 24, 2007 5:46 pm
Location: Toronto Harbour
Contact:

Re: Batteries vs Cold

Post by Lock » Feb 20, 2011 9:24 pm

DrkAngel wrote:...capacity is not effected so much as the "C" rating...
Important distinction. Tks DK!
If you like this message feel free to donate BeerCoins (BTC) to:
1LxAXWmbjY6SeMf8r9HHhSKt6pWyPvWg6L

Toronto Electric Riders Association:
http://www.ebikeriders.com/
Canada, eh?

User avatar
DrkAngel
10 GW
10 GW
Posts: 4462
Joined: Dec 15, 2010 11:14 am
Location: Upstate-Western-Southern Tier NY. USA

Re: Batteries vs Cold

Post by DrkAngel » Dec 10, 2011 10:04 pm

Cold is back, I could tell, because I set my bike outside, this morning ...
Made a run to the post office a few hours later, and my EZip battery leds were dipping into the red?
On a fresh charge!
Usually I can cruise at 20 mph for 20 miles before I see any red, (Summer).
These LiPo hold up to the cold, (20F), worse than, my standard 18650 Li-ion packs!

Continuing my 2010 thread.
Stay tuned for some great items and clever ideas!

Found some nice 12V pack warmers!!!
Last edited by DrkAngel on Dec 12, 2011 10:19 am, edited 4 times in total.
A little learning is a dangerous thing;
Drink deep, or taste not the Pierian spring:
There, shallow draughts intoxicate the brain,
And drinking largely, sobers us again.

I enjoy enlightening ... and enlivening the spirit of the innovators.

New & Improved - Acronym Definitions

Index - Homemade Battery Packs - Updated - November 2015

EBike Toolbox - Bargains! $

Endless Sphere Wiki

User avatar
neptronix
100 GW
100 GW
Posts: 13061
Joined: Jun 15, 2010 5:56 pm
Location: People's republic of Petrolistan ( Utah, USA )
Contact:

Re: Batteries vs Cold

Post by neptronix » Dec 10, 2011 10:09 pm

You've just discovered what the rest of the forum already knows.

Do you ever read this forum on your own, or do you pretend we don't exist until it's time to post?
My first major build: 8T MAC motor on a Trek 4500.
The new all-arounder: Leafmotor 1500w on a Turner O2 full suspension.
The wheelie machine: 20" Rear Magic Pie II on a Trek 4300 MTB

"The best time to plant a tree was 20 years ago. The second best time is now."- Chinese Proverb

User avatar
TylerDurden
100 GW
100 GW
Posts: 7543
Joined: Jan 04, 2007 5:50 pm
Location: Wear the fox hat.
Contact:

Re: Batteries vs Cold

Post by TylerDurden » Dec 10, 2011 10:20 pm

neptronix wrote:...do you pretend we don't exist until it's time to post?
That's a safe bet.
Have a Nice Day,

TD

___________________________________________________________

FYI: Adding pictures?

Bored?... take a crack at the unanswered posts

Please post your Watts-at-speed in the survey.




User avatar
DrkAngel
10 GW
10 GW
Posts: 4462
Joined: Dec 15, 2010 11:14 am
Location: Upstate-Western-Southern Tier NY. USA

Re: Batteries vs Cold

Post by DrkAngel » Dec 10, 2011 10:20 pm

Updating-continuing my 2010 thread!
DrkAngel wrote:Cold is back, I could tell, because I set my bike outside, this morning ...
Made a run to the post office a few hours later, and my EZip battery leds were dipping into the red?
On a fresh charge!
Usually I can cruise at 20 mph for 20 miles before I see any red, (Summer).
These LiPo hold up to the cold, (20F), worse than, my standard 18650 Li-ion packs!
As I mentioned previously, capacity is not as affected, as much as the C rate capability.
Voltage test, after 2 mile ride, was still near full ...

I will be reverting to my standard insulated lunch bags, might even experiment with pre-heating, or auxiliary pack heater.
Auxiliary pack heater, as opposed to self powered, from pack ... as a measurable drain vs performance increase.

Will probably handle bar mount my 6pack "Cool Cell" and give it a proper break-in, (37V 26ah - .96kWh).
Also tempted to drop in a couple heat packs, just pop em in a microwave for a bit, to keep my batts toasty.
Last edited by DrkAngel on Jan 02, 2016 10:45 pm, edited 5 times in total.
A little learning is a dangerous thing;
Drink deep, or taste not the Pierian spring:
There, shallow draughts intoxicate the brain,
And drinking largely, sobers us again.

I enjoy enlightening ... and enlivening the spirit of the innovators.

New & Improved - Acronym Definitions

Index - Homemade Battery Packs - Updated - November 2015

EBike Toolbox - Bargains! $

Endless Sphere Wiki

Joseph C.
1 MW
1 MW
Posts: 1998
Joined: Feb 03, 2011 8:43 am
Location: Ireland
Contact:

Re: Batteries vs Cold

Post by Joseph C. » Dec 10, 2011 10:36 pm

TylerDurden wrote:
neptronix wrote:...do you pretend we don't exist until it's time to post?
That's a safe bet.
:mrgreen:
Yellow Magpie - Home Of The Talented And The Interesting

http://yellowmagpie.com

User avatar
DrkAngel
10 GW
10 GW
Posts: 4462
Joined: Dec 15, 2010 11:14 am
Location: Upstate-Western-Southern Tier NY. USA

Re: Batteries vs Cold

Post by DrkAngel » Dec 11, 2011 12:16 am

Keep your battery packs warm.
Low wattage pads, in conjunction with insulation, should perk up your batteries, cold weather performance!

New Link>12v Flexible Adhesive Heatpads < $5/pair

Low wattage ... add as many as necessary!

Will run preliminary tests with separate power source, 3S Li-ion. To measure drain & performance increase.
Note: Should run nicely at 2S, or 1S, for less heat output! 4S, for more?

Ordered a few pairs, from China ...
But might take a couple weeks ... will post review, as soon as possible.
Attachments
Heat Pads.jpg
Heat Pads.jpg (79.26 KiB) Viewed 9736 times
Last edited by DrkAngel on Oct 10, 2013 12:38 pm, edited 5 times in total.
A little learning is a dangerous thing;
Drink deep, or taste not the Pierian spring:
There, shallow draughts intoxicate the brain,
And drinking largely, sobers us again.

I enjoy enlightening ... and enlivening the spirit of the innovators.

New & Improved - Acronym Definitions

Index - Homemade Battery Packs - Updated - November 2015

EBike Toolbox - Bargains! $

Endless Sphere Wiki

User avatar
DrkAngel
10 GW
10 GW
Posts: 4462
Joined: Dec 15, 2010 11:14 am
Location: Upstate-Western-Southern Tier NY. USA

Battery vs Cold

Post by DrkAngel » Dec 11, 2011 12:17 am

Everyone knows that cold degrades your batteries performance.

Solutions?

Insulate your pack.
For Li-ion, LiPo, LiFePO4 etc, insulated lunch bags, 6pack coolers etc, provide nice thermal protection.
Pre-warm your pack.
or ... add heat packs, gelled preferred, liquid might not be recommended!

Found a nifty little item that might be the best-cheapest solution!

Inexpensive, thin, flexible, self adhesive, low wattage heating pads.
DrkAngel wrote:Keep your battery packs warm.
Low wattage pads, in conjunction with insulation, should perk up your batteries, cold weather performance!
12v Flexible Adhesive Heatpads, < $5/pair
Low wattage ... add as many as necessary!
Heat Pad s.JPG
Heat Pad s.JPG (16.65 KiB) Viewed 9228 times
Perfect for eBike battery packs!
Will run preliminary tests with separate power source, 3S Li-ion. To measure drain & performance increase.

Ordered a few pairs, from China ...
Thought about it some more, ordered a few more pairs!
But might take a couple weeks ... will post review, as soon as possible.

Use your better judgment with batteries that tend to heat up, SLA, NiMh, RC Lipo etc.
Last edited by DrkAngel on Oct 10, 2013 12:35 pm, edited 5 times in total.
A little learning is a dangerous thing;
Drink deep, or taste not the Pierian spring:
There, shallow draughts intoxicate the brain,
And drinking largely, sobers us again.

I enjoy enlightening ... and enlivening the spirit of the innovators.

New & Improved - Acronym Definitions

Index - Homemade Battery Packs - Updated - November 2015

EBike Toolbox - Bargains! $

Endless Sphere Wiki

User avatar
lester12483
100 kW
100 kW
Posts: 1017
Joined: Jan 30, 2009 1:45 am
Location: Chicago, IL USA

Re: Battery vs Cold

Post by lester12483 » Dec 11, 2011 4:28 am

In my experience if you keep the battery at room temperature then you use it in the cold the performance is not degraded much. However if keep a battery pack in the cold garage then try to use it you'll notice a big difference. It also depends on how long you're riding in the cold.

If you wrap your battery in a towel it will help for better performance in the cold.
MT6 Hybrid- Electric Bicycle 48V
48V 13AH AllCell Lithium Manganese Battery Pack
http://www.chicagoelectricbicycles.com

User avatar
dogman dan
100 GW
100 GW
Posts: 34308
Joined: May 17, 2008 12:53 pm
Location: Las Cruces New Mexico USA

Re: Battery vs Cold

Post by dogman dan » Dec 11, 2011 7:15 am

Got a live thread in the battery section about this subject.

Those look ideal, chances are you could regulate the temp by changing the voltage. So if too hot at 12v, run on 8v? Could be great for that occasional need to ride a bike that has been parked out in the cold, while in class, shopping, etc.

If you can acess an ac plug, then the reptile heat pads are ideal. Flexible, small, waterproofed, won't get too hot, perfect.

User avatar
Ykick
100 GW
100 GW
Posts: 5944
Joined: Nov 26, 2009 6:10 pm
Location: San Diego, California

Re: Battery vs Cold

Post by Ykick » Dec 11, 2011 9:08 am

I add more battery capacity during winter cold.
Talent must not be wasted.... Those who have talent must hug it, embrace it, nurture it and share it lest it be taken away from you as fast as it was loaned to you.

- Frank Sinatra

User avatar
DrkAngel
10 GW
10 GW
Posts: 4462
Joined: Dec 15, 2010 11:14 am
Location: Upstate-Western-Southern Tier NY. USA

Re: Battery vs Cold

Post by DrkAngel » Dec 11, 2011 1:25 pm

Rig up the heat pads to a nice little programmable thermostat, and keep your batts nice & warm.
LCD programmable 12V thermostat - $15.99 w/shipping

Note: "Current on Relay Contact AC 5/220" ... Relay Contact should work fine at 12V DC! - AC-DC any voltage - 5A/220V max!
Attachments
Last edited by DrkAngel on Dec 13, 2011 12:39 pm, edited 1 time in total.
A little learning is a dangerous thing;
Drink deep, or taste not the Pierian spring:
There, shallow draughts intoxicate the brain,
And drinking largely, sobers us again.

I enjoy enlightening ... and enlivening the spirit of the innovators.

New & Improved - Acronym Definitions

Index - Homemade Battery Packs - Updated - November 2015

EBike Toolbox - Bargains! $

Endless Sphere Wiki

Post Reply
