Search found 60 matches

by BigBlock
Oct 22 2021 11:42am
Forum: EBike Build Threads
Topic: xKillah - Enduro eBike
Replies: 25
Views: 779

Re: xKillah - Enduro eBike

I'm still recovering from a recent crash during a MX race, so I decided to spend some time to improve my rendering skills.

by BigBlock
Oct 22 2021 9:13am
Forum: Stand-up EScooter/ESkateboards
Topic: EXTREMO - Scratch built 7kW billet frame scooter
Replies: 53
Views: 2898

Re: EXTREMO - Scratch built 7kW billet frame scooter

correct. this boy weight 50kg so the folding system can just help to better load in a car - non need to make thing too fancy
by BigBlock
Oct 20 2021 2:30am
Forum: Stand-up EScooter/ESkateboards
Topic: EXTREMO - Scratch built 7kW billet frame scooter
Replies: 53
Views: 2898

Re: EXTREMO - Scratch built 7kW billet frame scooter

yes, I designed the steering column to fold on the foot board - Just need to replace one bolt with a removable pin

by BigBlock
Oct 18 2021 3:34am
Forum: EBike Build Threads
Topic: xKillah - Enduro eBike
Replies: 25
Views: 779

Re: xKillah - Enduro eBike

the bolt you see will be joined by 30mm outer specers that will pack the whole assembly when properly tighten - I will share more detailed image later
by BigBlock
Oct 16 2021 12:11pm
Forum: EBike Build Threads
Topic: xKillah - Enduro eBike
Replies: 25
Views: 779

Re: xKillah - Enduro eBike

getting closer.... some motivational image in "Rosso Ferrari"

by BigBlock
Oct 16 2021 12:07pm
Forum: EBike Build Threads
Topic: xKillah - Enduro eBike
Replies: 25
Views: 779

Re: xKillah - Enduro eBike

by the way, I did calculations also without the shock mount constraint and the results are quite similar. This is because the loss of rigidity starts on the rear half of the swingarm, where the wheel does not allow for trinagulations (see colors in the FEM images below)
by BigBlock
Oct 16 2021 12:05pm
Forum: EBike Build Threads
Topic: xKillah - Enduro eBike
Replies: 25
Views: 779

Re: xKillah - Enduro eBike

BigBlock I think your simulation setup are wrong, don't lock the movement of the shock fixation. because shock will not take any torque or lateral force in real life. Just lock the main pivot in all direction ( and rotation), if your force are correctly apllied, it will don't want to rotate around ...
by BigBlock
Oct 15 2021 1:46pm
Forum: EBike Build Threads
Topic: 10kW, custom cut aluminum frame, QS205, full suspension
Replies: 45
Views: 2684

Re: 10kW, custom cut aluminum frame, QS205, full suspension

I agree that heat treatment is too complex and expensive for most DIY builders - it make sense if you weld in a jig that hold firm the part and remove the part from the jig once post treated in the hoven. Ususally when you weld on aluminum tubes (especially going on the longitudinal plane of the tub...
by BigBlock
Oct 15 2021 1:04pm
Forum: EBike Build Threads
Topic: xKillah - Enduro eBike
Replies: 25
Views: 779

Re: xKillah - Enduro eBike

the complete swingarm design is based on 3 cross steel rods that connect through a spacer the two arms and that will add stiffness to the whole assembly. The bottom rod is placed as close as possible to the wheel.... there is no any further space to cross-brace the swingarm in the rear area, where t...
by BigBlock
Oct 15 2021 11:43am
Forum: Stand-up EScooter/ESkateboards
Topic: EXTREMO - Scratch built 7kW billet frame scooter
Replies: 53
Views: 2898

Re: EXTREMO - Scratch built 7kW billet frame scooter

just finished to machine the new bracket and installed the dumper -

I did a test spin today and the handling has drastically imporved :D Now I can reach 90Km/h with one hand !!

by BigBlock
Oct 14 2021 2:35pm
Forum: EBike Build Threads
Topic: xKillah - Enduro eBike
Replies: 25
Views: 779

Re: xKillah - Enduro eBike

the type of design I use is based on billet piece of aluminium that have stronger and stiffer properties when compared to sheetmetal or tube welding fabrication. The disavantage is more weight if not proper engineered, because usually you have a lot of useless material where not needed. I use FEM ca...
by BigBlock
Oct 14 2021 1:24pm
Forum: EBike Build Threads
Topic: 10kW, custom cut aluminum frame, QS205, full suspension
Replies: 45
Views: 2684

Re: 10kW, custom cut aluminum frame, QS205, full suspension

are you welding with MIG or TIG ? you should try to limit the lenght of weldings where possible - I don't know how you managed the deformations on the piece - your weldings look very big and I guess the pieces got a lot of heat during the process. Unless you have a post stress relief thermal treatme...
by BigBlock
Oct 12 2021 1:32pm
Forum: EBike Build Threads
Topic: xKillah - Enduro eBike
Replies: 25
Views: 779

Re: xKillah - Enduro eBike

I'm doing good progress on the 3D - still need to work on few details, bearings and tollerances. Any hour spent on this tage is usually 3 hours saved during build.... https://i.ibb.co/MfLP4kt/1.png https://i.ibb.co/Bj0LTqC/2.png Quite happy with the size of the battery pack that is definitelly bigge...
by BigBlock
Oct 12 2021 12:01pm
Forum: Stand-up EScooter/ESkateboards
Topic: EXTREMO - Scratch built 7kW billet frame scooter
Replies: 53
Views: 2898

Re: EXTREMO - Scratch built 7kW billet frame scooter

HTTR wrote:
Oct 12 2021 7:41am
BTW, looking at the pictures again it looks like you put the tires on the wrong direction.
yes, you are right - Just fixed after the shots :lol:
by BigBlock
Oct 09 2021 4:05am
Forum: EBike Build Threads
Topic: xKillah - Enduro eBike
Replies: 25
Views: 779

Re: xKillah - Enduro eBike

this is the QS 138 V2 vs V3 vx Sur-ron Motor

by BigBlock
Oct 08 2021 2:05pm
Forum: EBike Build Threads
Topic: xKillah - Enduro eBike
Replies: 25
Views: 779

Re: xKillah - Enduro eBike

Hi, impresive project, your front frame is in one part? do you have another view where we can see more? don't really understand how do you plan to mill the frame. it's different parts bolted togheter; making a solid headtube connection without welding it's a bit triky. I have to do some FEM analisy...
by BigBlock
Oct 08 2021 2:02pm
Forum: EBike Build Threads
Topic: xKillah - Enduro eBike
Replies: 25
Views: 779

Re: xKillah - Enduro eBike

Great project and should come out very nice seeing your other build :thumb: Why not use the QS138 70H with build in reduction?: https://endless-sphere.com/forums/viewtopic.php?f=10&t=110723 I tried, but it's too wide and I would have to make the frame wider - I also looked to this one: MEMAX 17...
by BigBlock
Oct 08 2021 5:23am
Forum: EBike Build Threads
Topic: xKillah - Enduro eBike
Replies: 25
Views: 779

Re: xKillah - Enduro eBike

Some initial specs: Billet Aluminium 6082 frame (about 7Kg) with no welding Simplified manufacturing - frame components machinable with 3 Axis or water-jet CNC 3Kw QS Motor 138 70H - air cooled ASI BAC 4000 Controller 72V Battery Pack Improved Sur-Ron rear progressive shock geometry Two-step reducti...
by BigBlock
Oct 08 2021 5:12am
Forum: EBike Build Threads
Topic: xKillah - Enduro eBike
Replies: 25
Views: 779

xKillah - Enduro eBike

Hi, after having completed my first stand-up scooter project , I thought it's time for a new challenge... My new project is ispired to the popular Sur-Ron bike, with the aim to do something better that anyone can build by himeself (at comparable Sur-Ron price) with better components, more performanc...
by BigBlock
Oct 06 2021 3:17am
Forum: Items for Sale - New
Topic: QSMOTOR,0.5-12kW Electric Hub Motor & Mid Drive Motor Manufacture China
Replies: 1453
Views: 328321

Re: QSMOTOR,0.5-12kW Electric Hub Motor & Mid Drive Motor Manufacture China

Hi,
any chance to have a 3D CAD model of the QS138 70H v3 (with gearing sprocket) ?

It will help many of us to design the frame bracket meanwhile waiting the delivery.

Thanks.
by BigBlock
Oct 02 2021 10:31am
Forum: Stand-up EScooter/ESkateboards
Topic: 10kW stand-up scooter with air suspension
Replies: 275
Views: 72788

Re: 10kW stand-up scooter with air suspension

outstanding job Alex !! The liquid cooling path integrated in the side plate is genious. :bigthumb:
by BigBlock
Oct 02 2021 5:28am
Forum: Stand-up EScooter/ESkateboards
Topic: EXTREMO - Scratch built 7kW billet frame scooter
Replies: 53
Views: 2898

Re: EXTREMO - Scratch built 7kW billet frame scooter

I did a quick modelling in 3D to find the right spot. It was a little bit triky and I end up with a similar setup seen on Dualtron and other scooter of that size. There is litellary no space to put it in a more hidden spot. I finally managed approx 30 degree of steering - the dumper will work also a...
by BigBlock
Oct 02 2021 5:14am
Forum: Stand-up EScooter/ESkateboards
Topic: EXTREMO - Scratch built 7kW billet frame scooter
Replies: 53
Views: 2898

Re: EXTREMO - Scratch built 7kW billet frame scooter

thanks for the feedback.

it's now time to work on initial improvements. I would like to see how a steering dumper will improve the handling, thus I got this little guy here:

by BigBlock
Oct 02 2021 5:10am
Forum: Motor Technology
Topic: Nanjing far driver controllers
Replies: 34
Views: 2915

Re: Nanjing far driver controllers

I used the mobile app that looks to have all configs available. The PC software is only partially transalted in english.... Standard NTC temp sensor, no problem. The wiring harness provides typical plugs for this kind of controller (low brake, high brake, key, 3-speeds, cruise and even a sound allar...
by BigBlock
Sep 30 2021 11:34am
Forum: Motor Technology
Topic: Nanjing far driver controllers
Replies: 34
Views: 2915

Re: Nanjing far driver controllers

I got a couple of ND72330 rated @ 150A and I would say they work quite well - Very easy to configure. They provide an auto-learn features to accelerate the initial process. So far so good. For the price (approx. 150 euro/each) it's a fair product. Need more time to say how it goes in long term https...
