Greetings!
The goal of this project was to cram as much power as possible into a reasonably small and light package. At 50 kg or 110 lbs, it's not exactly a mountain bike, but it's still far from a full sized dirt bike. And after working on my 2 wheeled inline skateboard project, I wanted to stay away from small power dense, high rpm motors that require complicated reduction drives to get useful torque. That meant a large, low rpm torque monster like the ME4201. Sure, I had to remove the rear fan and cover to make it fit my frame, but it hasn't had any overheating issues yet. Pretty sure that's a good excuse to buy a bigger controller and put more power though it!
The goal of this project was to cram as much power as possible into a reasonably small and light package. At 50 kg or 110 lbs, it's not exactly a mountain bike, but it's still far from a full sized dirt bike. And after working on my 2 wheeled inline skateboard project, I wanted to stay away from small power dense, high rpm motors that require complicated reduction drives to get useful torque. That meant a large, low rpm torque monster like the ME4201. Sure, I had to remove the rear fan and cover to make it fit my frame, but it hasn't had any overheating issues yet. Pretty sure that's a good excuse to buy a bigger controller and put more power though it!
- AussieJester 100 GW
- Posts: 8736
- Joined: Mar 11 2008 3:33am
- Location: Perth Western Australia
Re: Lightweight ME4201 Offroad Build
Thats one hell of a build mate hugely impressive! Definitely grab a MX seat perhaps something from 50cc size bike Honda cr50 for example.
KiM
KiM
Re: Lightweight ME4201 Offroad Build
What a work of art. The frame looks top notch.
Are you planning on a product run? If so please advise.
I have a build using the same forks, rims, hubs and tyres on a Qulbix 76r.
Great to see another quality mid drive build. Please post more vids.
Subscribed
Are you planning on a product run? If so please advise.
I have a build using the same forks, rims, hubs and tyres on a Qulbix 76r.
Great to see another quality mid drive build. Please post more vids.
Subscribed
Re: Lightweight ME4201 Offroad Build
The 18650 brackef look nice. Where did you get them? And why did you remove the cells shrink wrap?
- skeetab5780 10 MW
- Posts: 2432
- Joined: Jun 15 2009 10:58pm
- Location: MA
- Contact:
Re: Lightweight ME4201 Offroad Build
Very sick! Subd
Youtube channel http://www.youtube.com/skeetab5780
Kuberg Freerider Project viewtopic.php?f=28&t=90187
Direct Drive Genesis http://endless-sphere.com/forums/viewto ... 28&t=59122
Voloci Pageviewtopic.php?f=12&t=58410&p=1372424#p1372424
Denzel 4-Spd Electric Dirt Bikeviewtopic.php?f=12&t=99606&p=1580294#p1580294
Kuberg Freerider Project viewtopic.php?f=28&t=90187
Direct Drive Genesis http://endless-sphere.com/forums/viewto ... 28&t=59122
Voloci Pageviewtopic.php?f=12&t=58410&p=1372424#p1372424
Denzel 4-Spd Electric Dirt Bikeviewtopic.php?f=12&t=99606&p=1580294#p1580294
Re: Lightweight ME4201 Offroad Build
If nothing else from this project, I learned that there is a reason most bike frames are welded structural tubes. All of the 20 or so water jet cut parts had to have their mating surfaces machined flat and drilled and tapped to match. I spent the better part of a month staying a couple of hours after work each day to finish the machining. It also takes a lot more effort to make a stiff frame when you are working with flat plate as opposed to tube. So, to answer your question, I would not want to go into production with this style frame. It's cool because it's easy to change or modify something, but it was a lot of extra effort that could have been spent actually learning to weld!
The cell spacers were just 3D printed in a layout that made sense to me at the time. The fit ended up being a little tight, and I had to hammer the 2 halves onto the cells. Pulling the wrapper off the 18650's made the fit a little easier. I can add the STL file to the grabcad page if interested. I probably should have just adjusted the scale of the file, but I was impatient.
The cell spacers were just 3D printed in a layout that made sense to me at the time. The fit ended up being a little tight, and I had to hammer the 2 halves onto the cells. Pulling the wrapper off the 18650's made the fit a little easier. I can add the STL file to the grabcad page if interested. I probably should have just adjusted the scale of the file, but I was impatient.
Re: Lightweight ME4201 Offroad Build
Congrats that is a great effort, sounds like you learned at lot in during the design and build. Looks pretty cool too

-
- Posts: 2075
- Joined: Oct 06 2012 4:45pm
- Location: SF Bay Area
Re: Lightweight ME4201 Offroad Build
A few years ago I visited the Tesla Showroom , when it was in Menlo Park, next to Palo Alto.
They had a rolling chassis sitting on the Showroom Floor ( just lower part of the car with wheels , cut away to show where the batteries and motor go. etc.
Looking closely I noticed that there were few, if any , welds, If I remember right there were No .. welds , it looked like one part was inserted to another part then glued/bonded to each other.
I asked the salesperson about this and he confirmed that the chassis was indeed bonded together.
You do not , have , to learn welding. Bonding ( with a few bolts for added piece of mind , make them aircraft bolts ) could and even should work better .
They had a rolling chassis sitting on the Showroom Floor ( just lower part of the car with wheels , cut away to show where the batteries and motor go. etc.
Looking closely I noticed that there were few, if any , welds, If I remember right there were No .. welds , it looked like one part was inserted to another part then glued/bonded to each other.
I asked the salesperson about this and he confirmed that the chassis was indeed bonded together.
You do not , have , to learn welding. Bonding ( with a few bolts for added piece of mind , make them aircraft bolts ) could and even should work better .
Vertigo wrote:If nothing else from this project, I learned that there is a reason most bike frames are welded structural tubes. All of the 20 or so water jet cut parts had to have their mating surfaces machined flat and drilled and tapped to match. I spent the better part of a month staying a couple of hours after work each day to finish the machining. It also takes a lot more effort to make a stiff frame when you are working with flat plate as opposed to tube. So, to answer your question, I would not want to go into production with this style frame. It's cool because it's easy to change or modify something, but it was a lot of extra effort that could have been spent actually learning to weld!
My first conversion ... Sold
viewtopic.php?f=3&t=71378&p=1077497&hil ... 1#p1077497
It's 2018 already, ( now 2019 ) lets get some real , improved e-bike / e-velomobile / e-motorcycle designs .
viewtopic.php?f=3&t=71378&p=1077497&hil ... 1#p1077497
It's 2018 already, ( now 2019 ) lets get some real , improved e-bike / e-velomobile / e-motorcycle designs .
-
- Posts: 161
- Joined: Jul 23 2013 6:44pm
- Location: Fort Wayne, IN, USA
Re: Lightweight ME4201 Offroad Build
Updates?!?! This thing is awesome!
Waiting for that perfect ebike.
Re: Lightweight ME4201 Offroad Build
That is some really nice work dude. Freakin awesome.
-
- Posts: 196
- Joined: Aug 02 2014 10:34pm
Re: Lightweight ME4201 Offroad Build
did you use specific wire to solder the 18650's ?
-
- Posts: 173
- Joined: May 11 2015 7:16am
- Location: Italy
Re: Lightweight ME4201 Offroad Build
Awesome build Vertigo!
I am looking forward to for the new update!
I am looking forward to for the new update!
- skeetab5780 10 MW
- Posts: 2432
- Joined: Jun 15 2009 10:58pm
- Location: MA
- Contact:
Re: Lightweight ME4201 Offroad Build
Swingarm looks like it will flex all over! Be careful
it is a definite showroom piece!
it is a definite showroom piece!
Youtube channel http://www.youtube.com/skeetab5780
Kuberg Freerider Project viewtopic.php?f=28&t=90187
Direct Drive Genesis http://endless-sphere.com/forums/viewto ... 28&t=59122
Voloci Pageviewtopic.php?f=12&t=58410&p=1372424#p1372424
Denzel 4-Spd Electric Dirt Bikeviewtopic.php?f=12&t=99606&p=1580294#p1580294
Kuberg Freerider Project viewtopic.php?f=28&t=90187
Direct Drive Genesis http://endless-sphere.com/forums/viewto ... 28&t=59122
Voloci Pageviewtopic.php?f=12&t=58410&p=1372424#p1372424
Denzel 4-Spd Electric Dirt Bikeviewtopic.php?f=12&t=99606&p=1580294#p1580294
Re: Lightweight ME4201 Offroad Build
Would it be helpful to sandwich the swing arm between layers of carbon fiber and get added strength against flexing?
Re: Lightweight ME4201 Offroad Build
Hi Vertigo. That looks sic!
How much torque at the rear wheel do you get with that and at what amps?
How much torque at the rear wheel do you get with that and at what amps?
Re: Lightweight ME4201 Offroad Build
Hey, you got any more pics?
-
- Posts: 144
- Joined: Feb 22 2014 8:40pm
- Location: FRANCE
- Contact:
Re: Lightweight ME4201 Offroad Build
haaaaa
and you give us our chance ...

Man ... a big BiG Thanks to you and all your amazing work and sharing all !!! your model is so gorgeous, but now cause of you I will have to make one one day haha
(I'm a big fan of LMX ! I just comeback from many yrs of esk8 and e-mtboarding, try e-Dirt Scooter, and biking but all start here around 8 yrs ago more or less, looking for ebike. So now I will start to make my 1st little ebike to train myself in the e-bike world. But I could already think to the futur now)
is the motor extremly noizy or just the wind effect ?
Big Up


Man ... a big BiG Thanks to you and all your amazing work and sharing all !!! your model is so gorgeous, but now cause of you I will have to make one one day haha


is the motor extremly noizy or just the wind effect ?
Big Up
