Your Creation's Before & After Pics

Post by babyhughie » Jun 03 2014 6:44pm

Here's my recently somewhat finished bike.. Still need to put a rear rack and panniers/saddle bags and a suspension front fork. It seems like this could be a never ending project but right now it's full functional and very fun to ride.

-Bike is a Fito Modena GT 7speed.

-Yescomusa 1000w hub motor kit

-Schwalbe marathon 26"x2.0" rear tire, CST Cyclops 24"x2.4" front tire

-Large Revelate Designs triangle bag

-Calibattery 48v 15ah battery

After pics.

Before.

rolls   10 mW

10 mW
Posts: 26
Joined: Apr 07 2014 6:44pm
Location: S.E. NSW, Australia

Re: Your Creation's Before & After Pics

Post by rolls » Jun 04 2014 6:22pm

jansevr wrote:wow nice build rolls! although most people use the giant dhs for the triangle space i think it gives the bike a nice look having that open. the kiwi front battery mount is a great piece as well! my guess is that the battery box most likely balances the bike out (with the motor in the rear)? what was your reasoning and your experience with it?

also - what forks are those...they look like they might be pit bike forks or something other than dh? very beasty looking
The bike has arrived at it's current state from me "going with the flow", that is putting on whatever was cheapest/best for what was needed as I built it.

I got ripped off on the bike itself. It was an ebay special in Sydney, ~280km away, so I asked my sister (non bike person) to pick it up for me and I drove to her place a week later. The bike was F%^&*ed. Nearly everything on it was stripped, burred, or just outright stuffed. HA - the back wheel was good, but didn't need it! I needed a new swingarm and shock, and bought them from another forum member who also had the Kiwi batt holder. I was going to put the battery there anyway, but the battery holder was a quicker fix.

The battery wouldn't fit in the triangle (only just). The battery is a work of art in itself, built by another forum member in Perth. http://www.endless-sphere.com/forums/vi ... 31&t=38252

The forks, according to a local bike suspension business, Suspensionsmith, are from a downhill bike, although he couldn't tell me what brand they are. They need a service, so I'll find out sooner or later what they are. (white bros?). I painted the lowers with a rattle can. The "V" angle on the triple clamps is quite deep, and so there was enough room behind the batt holder to put the infinion 7240 controller. I was going to put the controller under the downtube , and that's why I put a water bottle cage on with hose clamps. The middle hose clamp has the shock reservoir riveted on to it.

Just this morning I've been given bright red vinyl decals for the downtube "VITA NOVA", latin for NEW LIFE (for an old hack). New pics soon.

Rolls.

bergslag   1 µW

1 µW
Posts: 1
Joined: Jun 05 2014 5:36pm

Re: Your Creation's Before & After Pics

Post by bergslag » Jun 05 2014 6:36pm

72V battery at 33 amps, 15ah
http://www.bmsbattery.com/packs/531-48v ... -pack.html

85V fully loaded gives me about 2400W making it 61km/h on the flat (37.9mph) and about 50km/h in really strong headwinds.
Fastets speed downhill at 70km/h (43mph)

The motor is wide (145cm) so i bought a steel bike, that way i could bend the dropouts.
http://cnebikes.en.alibaba.com/product/ ... _kits.html

The axle on the motor is wide (oblong) so it had to be dropouts on a single speed bike (where you can adjust the chain by moving the wheel back)
Otherwise i could not fit the motor on the dropouts.
This bike also has disc brakes but because of the placement of cable from the motor i could not fit the rear disc breaks.
I fitted shimano hydralic disc breaks at the front wheel, making a big different compared to the mechanical.

A welder made a compartment for the the big battery.
http://www.bjornssvetsosmide.se/

I also has a ignition key or switch key so nobody is able to play with the throttle when i am in a store.
Of course i always lock my bike with a cable.

I bought a portable bicycle basket for the luggage rack.

With this setup i am able to go to store and be away for about 10 min.
I can also remove the battery and hang the bike on the wallcarrier.

The charger is at 4 amps, making it from totally empty to full in less than 4h.

Torque arms are fitted on both side of the rear wheel, rev 2 and rev 4 for extra safety:
http://shop.crystalyte-europe.com/home.php?cat=299

What more...yes the tires is spectra DURAMAX X-5 (witch 5mm rubber puncture protection)

/thanks
Attachments

Wheels_78   100 mW

100 mW
Posts: 36
Joined: Aug 27 2010 3:18am
Location: Edmonton, Alberta

Re: Your Creation's Before & After Pics

Post by Wheels_78 » Jun 23 2014 1:33am

Before


After


Motorcycle saddlebags enroute to replace the backpack, and I might just add fenders to complete the "chopper" look.

toula.tomas   1 W

1 W
Posts: 51
Joined: Jun 29 2014 4:27pm

Re: Your Creation's Before & After Pics

Post by toula.tomas » Jun 30 2014 5:37pm

Image :twisted:

Snelheid Cycles   1 mW

1 mW
Posts: 14
Joined: Jun 30 2014 3:35pm
Location: Chicago, IL USA
Contact:

Re: Your Creation's Before & After Pics

Post by Snelheid Cycles » Jun 30 2014 6:28pm

June '14 2.jpg
Snelheid Prototype 002
Here's my daily ride. I don't have a before pic as I built it from the frame up as an E-Bike. Here are it's main features:

- Heavily modified Chromoly Single Speed Track frame
- Alex DH-19 wheels with Schwalbe Energizer Plus tires (700c x 35mm)
- Lyen 6Fet controller with Low/High switch capable of handling 36v - 90v
- Mac Motor
- Custom CAD drawn, laser cut Carbon Fiber battery box
- Integrated On/Off switch
- Integrated 3 speed switch
- External "Powerkey" which disconnects the controller from the Battery pack when not in use
- Handlebar mounted digital gauges. Voltage(Blue), Motor Temp(Red)
- Aluminum Wire covers
- Custom wiring from the throttle to the motor
- 10awg/8awg Phase wires with 4mm connectors for easy rear wheel removal
- 10awg Battery Wiring Harness with color coded APP 45A connectors
- External Charge Port (1)
- External Balance Ports (4)
- Quick release mount for CA
- Cyclometer hardwired to rear wheel
- Zero (0) Zip Ties
- Zero (0) Duct Tape

I've configured it to run on several variations using Lipo batteries. I've tested it at 37v, 44.4v, 52v, 74v, and 88.8v ranging from
370w/hr - 444w/hr. 20 - 30 mile range. 1 - 1.5hrs charge time (10A)

37v = 20mph, 88.8v = 40+mph

370w/hr = 44.8lbs, 444w/hr = 46.4lbs

Tony
www.snelheidcycles.com
Attachments
June '14.jpg
Snelheid Prototype 002

User avatar
Samd   1.21 GW

1.21 GW
Posts: 3667
Joined: Jun 28 2011 11:08pm
Location: Ballarat, AU
Contact:

Re: Your Creation's Before & After Pics

Post by Samd » Jun 30 2014 10:38pm

toula.tomas wrote:Image :twisted:
Nice frame up - I assume not many watt hours inside?
Looks like it's had some fun with the mud :)
http://ballaratebikes.com/

"Knowledge is knowing that a tomato is a fruit. Wisdom is knowing that a 165mm rear shock can't deliver 220mm of rear swingarm travel." - Oprah Winfrey.

toula.tomas   1 W

1 W
Posts: 51
Joined: Jun 29 2014 4:27pm

Re: Your Creation's Before & After Pics

Post by toula.tomas » Jul 01 2014 5:19am

Samd wrote:
toula.tomas wrote:Image :twisted:
Nice frame up - I assume not many watt hours inside?
Looks like it's had some fun with the mud :)

10Ah LiFepo4 72V

zepolaon   1 µW

1 µW
Posts: 3
Joined: Jun 23 2014 11:30am
Location: Illinois, USA

Re: Your Creation's Before & After Pics

Post by zepolaon » Jul 04 2014 12:02pm

Where did you go to get your hub motor? I have been looking at Bafang for their mid drive motors, but like you I will be unable to park it inside :( . Therefore, stealth is also a big part of my design.

User avatar
fesanand   10 W

10 W
Posts: 98
Joined: Jun 01 2014 5:48am

Re: Your Creation's Before & After Pics

Post by fesanand » Jul 05 2014 9:03am

toula.tomas wrote:
Samd wrote:
toula.tomas wrote:Image :twisted:
Nice frame up - I assume not many watt hours inside?
Looks like it's had some fun with the mud :)

10Ah LiFepo4 72V

Pretty machine!!!! interesting front light. Could you please post more pics of the front view, and top view handlebar or "cockpit"?

1KW   1 kW

1 kW
Posts: 341
Joined: Jul 24 2013 10:23am

Re: Your Creation's Before & After Pics

Post by 1KW » Jul 05 2014 10:29pm

yep^ that thing is so sick

rinky tinker   1 µW

1 µW
Posts: 2
Joined: Jul 06 2014 3:28pm
Location: Central Coast California, USA

Re: Your Creation's Before & After Pics

Post by rinky tinker » Jul 06 2014 3:45pm

I put a Bafang BBS01 350w on my old Specialized M2 mountain bike with a 36v bottle battery:

http://i1375.photobucket.com/albums/ag4 ... 5e0f35.jpg http://i1375.photobucket.com/albums/ag4 ... a0315f.jpg


The hardest part of the conversion was changing out the 20+ year-old elastomers in the old manitou fork (what a mess.)

Thanks to all on this board, especially the Bafang mid-drive thread

toula.tomas   1 W

1 W
Posts: 51
Joined: Jun 29 2014 4:27pm

Re: Your Creation's Before & After Pics

Post by toula.tomas » Jul 09 2014 5:08pm

hard to make glass

toula.tomas   1 W

1 W
Posts: 51
Joined: Jun 29 2014 4:27pm

Re: Your Creation's Before & After Pics

Post by toula.tomas » Jul 09 2014 5:10pm

12W led

1KW   1 kW

1 kW
Posts: 341
Joined: Jul 24 2013 10:23am

Re: Your Creation's Before & After Pics

Post by 1KW » Jul 13 2014 11:03am

18s10ah,9c,15fet 50 amp.

User avatar
Samd   1.21 GW

1.21 GW
Posts: 3667
Joined: Jun 28 2011 11:08pm
Location: Ballarat, AU
Contact:

Re: Your Creation's Before & After Pics

Post by Samd » Jul 14 2014 1:21am

Another custom mod frame for ES user PRW.

Before:
After:
Build thread:
http://endless-sphere.com/forums/viewto ... =6&t=61573
http://ballaratebikes.com/

"Knowledge is knowing that a tomato is a fruit. Wisdom is knowing that a 165mm rear shock can't deliver 220mm of rear swingarm travel." - Oprah Winfrey.

User avatar
soaresdacosta   1 kW

1 kW
Posts: 461
Joined: Jan 26 2011 12:08pm
Location: Portugal / Europe

Re: Your Creation's Before & After Pics

Post by soaresdacosta » Jul 15 2014 8:50am

My first e-bike, already have ideas for a new one.
Build: http://endless-sphere.com/forums/viewto ... =6&t=38754
Attachments

xmasta   10 W

10 W
Posts: 91
Joined: Apr 04 2011 2:38am
Location: Tallinn, Estonia

Re: Your Creation's Before & After Pics

Post by xmasta » Jul 28 2014 1:54am

Here's my third build.

Before:
ebike-xm-t1-before
After:
ebik-xm-t1-done
And a short video about how it came to be:


More at my thread http://endless-sphere.com/forums/viewto ... =6&t=29621

edit: fixed youtube embeb
My build: 9C rear DD + Greentime 15fet + 60v Lipo (4s1p x12 hardcase hobbyking)(now on second set) (RIP)
New built at "xm-blue" (Q100H "kit" test from bmsbattery.com)

User avatar
fesanand   10 W

10 W
Posts: 98
Joined: Jun 01 2014 5:48am

Re: Your Creation's Before & After Pics

Post by fesanand » Aug 01 2014 4:42pm

Before


After:



DD Hub Kit 1800Watt
Recycled laptop batteries, 18650 cells 14S8P 58v 16Amp
Homemade Metal case + vinyls
2 x Arm Torques (without them Hub spin out in the first test)

Upgraded components:
Raleigh Avenir Gel Sprung Saddle Best Buy Ever!!!!
Handlebar
Suspension Forks
Front mudguards Topeak XC1 (a classic)
Tyres: SCHWALBE CITY JET 26X1.95
185mm avid front disc
160mm avid rear disc

fatbikebuilder   1 W

1 W
Posts: 54
Joined: May 25 2014 12:04am

Re: Your Creation's Before & After Pics

Post by fatbikebuilder » Aug 02 2014 9:45am

please take a look at this video lin. it shows my page of electric fatbikes. please tell me what you think of the videos thanks. you can search more videos by subscribing or clicking more videos on page.
Last edited by fatbikebuilder on Sep 16 2014 10:05pm, edited 1 time in total.
Carver titanium obeast 24s 100.8 volt 5000 watt aircooled thunderbolt motor overclocked to 6200 watt. Mongoosebeast disc brake conversion 72 volt lyen controller,surly pugsley 7240 kit from electric rider.

fatbikebuilder   1 W

1 W
Posts: 54
Joined: May 25 2014 12:04am

Re: Your Creation's Before & After Pics

Post by fatbikebuilder » Aug 02 2014 9:48am

this is a close up view of 2 90 volt 5000 watt carver titanium beast fatbikes powered by 24s 90 volt hpc extreme packs. rock shox bluto forks. check other videos on page or subscribe to get updated videos. thanks for lookin and tell me what you think.tYdbwaIRJ1U
Last edited by fatbikebuilder on Sep 16 2014 10:05pm, edited 1 time in total.
Carver titanium obeast 24s 100.8 volt 5000 watt aircooled thunderbolt motor overclocked to 6200 watt. Mongoosebeast disc brake conversion 72 volt lyen controller,surly pugsley 7240 kit from electric rider.
