esk8 2015 - e-MTB 2015/16 - e-pintail 2016

OH YEAH!! I'm so happy for you Bro, finally it work great.

All of this because of a bad firmware :? , damnit..

Hi there !
some change happened, I take my Alien kit for a e-mtb build (winter project) with a new one I have oder to APS.
So this board is going to be ride with a 150A Hobbyking esc and 6374 SKY TURNIGY motor ... and for now just a 5S I have more :roll:
Some photo before to remove the APS kit :

I never go up to 35kmh because of me and my capacity but e-ride is soooooo cool, I think e-mtb going to be as good as e-sk8 !

Good ride every one !

Hi there its been a long time !

Some news :

  • e-longboard sold
    to Simon Perdrix from Live The DreamTour, dirt Bike rider who take 50km/h on the Alien single drive setup !
    [youtube]Lm5_r8wOkGk[/youtube]
    15min of ride on topspeed he told me :lol: I never push the board that hard, he is a crazy rider and love the board so I'm pretty happy :D



I want an all-road board to ride everywhere : The Darth Vapor
[youtube]h-cPR9wv8_M[/youtube]

more to come in the next post ! :p

thanks for your patience and to google translate !

Here is some pics of my process, it will tell you more about what I have done than me and my bad franglish :roll:

Here is the beautiful baby 7.8kg and 40", named Furnace Creek Scrub, SERIES 2, shod in 9", adopted on the net for 90€ :arrow:

Firt time I trie Mountainboard, the is strictly different than longboard, fixed foot is wired ... I have to learn !!!
and it's really really flexy, smooth, turn/carve good

The Deck
[youtube]ph0P6J2xhVE[/youtube]


[youtube]Wlvha9XW8DI[/youtube]




[youtube]h0MMOUhE_dY[/youtube]

[youtube]2b65dDwybos[/youtube]
:lol:
[youtube]b6z-meKKEc4[/youtube]

The carbone really turn the flex more stiff, reactive !! Here is for the deck :) hope you like it !

Good ride :wink:

For the electronic :

2 x VESC (+Pack CAN Bus, wire JST-PH 4 pin)
4 x battery Lipo 3S 5000mAh 20C
2 x motor AlienPowerSystem 6374 170KV 3200W
connectors XT90-S Anti-Spark
connectors HXT 4mm Gold
connectors 5.5mm or
Silicone Wire 10AWG 2 or 3 m de red & black
Fusible 80A (thx OKP !)
Transmetteur GT2B 2.4GHz (3CH ) OKP custom remote + Receveur + Batterie Li-ion rechargeable
Charger iMax 6B Mini de SKYRC




Here is my connection diagram


More to come :arrow:

Transmition

for the motor mount it's Willozbaord who advice me about a kit :
2 x Motormounts short Alu 6mm (wilding on truck)
1 x Truck Trampa Vertigo
2 x Wheelsprockets 65T
2 x Motorsprockets 12T (D10 avec 2 vis de serrages à 90°)
10 x screws
2 x Chains #25 ( avec 2 x Kit "speed lock")









à suivre !

thanks Whitepony :D !!!

Now will start the questions :lol:

I have somes problem with my APS motors ... (just 4/5 test ride with my board)
They get the wiring motor gnawed/eaten :| ... maybe some of you get an idea about how to prevent/avert the cut :idea:



But, more, I have one who start being drilled/used/milled(factory) ... sorry Google translate

I dont know why,... the other get nothing, no residue ... and now is cage move, translate along the axe ... really freaky :!:

a very friendly frensh rider "No Rules" lend me two engines for test !!! Very cool to him :p thanks to e-rider community !
he don't use them cause they got both the same problem as me ! One like my first photo, the other the open one, with a missing wire (cut with time) ... It seams to be a recurring problem :?

new build for summer !? :D yes I want ! and the last deck of Whitepony really motived me (congrat' once again for all your work man ;) )
Sorry for the poor vid ... I like it and I start film whit my phone ... just testing the "proto"

[youtube]UNRCD8AmUbg[/youtube]

Its been more than 7 months I didn't ride a e-sk8 (in single drive), it was sold for the e-mtb build.
It really miss also, the "free-wheel" what a pleasure !! So quiet vs the Darth Vapor :lol:
and the alf of autonomy. Here 2 x 5.5km ride with really high clambing (sorry not sure about the transduction) = 2300Amh
.
Deck : Original Longboard 40"
Mount drive : DIYES v4
Motor : Dymond 6374 200kv 3kW
ESC : VESC 2.18
Remote : GT2B custom by OKP
Battery : 3 x 3S 5Ah




it will be a 10s at final and actualy vesc is setup at 75A max for motor (85A in real) and 0.03 start up boost
do you make some other programmation on your vesc ?

thanks guys & good ride :wink:

hah! nice board, would be cool to see it with their s8 trucks instead of calibers, always wanted to try those! :eek:

your pavement looks like the pavement I got - mixed stuff with partially pretty bad patches! if you can, lend yourself some 90mm abecs by one of the french community - its a lot smoother to ride compared to kegels! its kegels all over the place, probably because they look cool - but from a riding comfort point of view, they arent even close to the 90mm abecs! 8)

also, like people told me and I didnt want to believe at first: for a single drive, 15mm belt drive is really a lot better and also safer. after the 9mm belt wears down a little, the slipping will start.

looking forward to your build :)


p.s.: didnt know that motor yet, looks really cool :eek:

Many thanks for your feedback Whitepony !!!
yeah the 200 mm original truck S8 could be fine on it but ... I have to look to the adaptator !
Should be really more fun on e-sk8 like you say, cause when you start puching at the beggeing (my firt deck for go work to Paris) its hard cause the wheels exceeds too and I often take my feet in early :mrgreen:
Yes true, many thanks, I have a pack of 97mm ... :lol: but waiting for the adaptor from APS and so I would try 15mm :D but I have heard that there is no differences ... you reassure me !
This setup will be put in a smaller deck (31,5") for my GF.
I will make almost the same for me, on this pintal, with 10s, and 97mm so... I have 14T and 16T ... but 14Tx36T will works with 97mm wheels !? What do you think guys ??

The motor : DYMOND GTX-6374


good DIY & good ride :wink:

Pict will say more and better than me :)

ciao bella :cry:

shaping the box, and sanding the holes :

make a mold for motor cage in 3D print :

let's go !

for the mold accept the pression of the pump :

Best old color t-shirt find for Kegels, test/stratification :

with the holes in box, ready to epoxy :


Surprise inside !!


3D inscustation :


Now witing for 24H ... :wink:

awh, awesome - seeing these pictures makes me wanna build another board!! :lol:

I like how you added these screw hole plateaus - its something I thought long about when I build my vanguard enclosures - visually I like it a lot more like you did it, but you probably cant tighten the screws very hard, so you would need some foam/rubber between enclosure and board to seal it?

also very nice how you 3D printed the boards name in the enclosure, cool ideal!! :)

what vacuum do you use with that foam? full pressure of slightly less than max to keep the foam alive?

hahaha, that is cause of you :mrgreen: ( a little bit cause of your vanguard) !
So hurry to try this !!!.. and next I will start making my deck (more downhill style) to test and see how rigide board feels. And could undle more speed maybe
And if its not for me, I will stay with this one but to much flex so this will finish by a full carbonification of the deck :) ...

You right, " tighten the screws very hard" will be hard but thinking like you say, and with something like this rubber mount for screws too


I have to admite I do exaclty the same than for my e-mtb ... full pression ... during 9h ...
I see what that could made to the finish ... but for this proto it will fine ... :D and its just a test.

For the next board, the one I have to make (downhill style), no more prototyping/test (saving money) so I will do it just like you, in a piece of wood ;) and with carbone fiber :wink:

here is the result guys !
just 1.5mm extrude 3D logo works pretty well !! you think more could be better ? (3mm ? too much maybe, it will be in carbone for the next time :p )



no plate for holes ... too much "ply" ... but it's a test ...

for the next it will be with carbone so it will be okay (here my UD fiber glass is too big, and the old t-shirt not "iron" don't help) and I have to pre-cut more correctly the "plus" of fiber to the mold size ...
(sorry for this english "translation")

[youtube]GCc7BruVUrE[/youtube]

hope you enjoy it ! :wink:

thats a really nice timelapse video and a great idea with the cloth "fibers". its probably hard/impossible to sand, but it has a very interesting look & texture! also a great idea with the logo texture under the cloth! :D
