by MitchJi » Aug 15 2014 10:42am
Hi,
The individual cells are 15AH, which are rated conservatively by GM at 7.8C. They are welded together in 3P 45AH groups, which are welded into 6S and 12S modules. That is a substantial disadvantage because it makes it very difficult to reconfigure the packs.

- VoltBlades2.jpg (105.47 KiB) Viewed 16301 times
It looks like the plates on the end might be used to compress the modules?
The module dimensions are 11" high and 9.5" wide. The Volt packs have 7 modules with 12 groups (~48v ) that are 9.2" long and 2 modules with 6 groups (~24v) that are 4.6" long.
There is a thread on the DiyEv car forum with quite a bit of info (prices paid range from $2000 + $150 shipping to $1,3xx picked up locally):
http://www.diyelectriccar.com/forums/sh ... 93101.html
Including some information on separating cell groups and individual cells:
http://www.diyelectriccar.com/forums/sh ... tcount=108
To do the individual cells, get a 26" x 1.75/2.25 bicycle tube. Cut off 1" slices like rubberbands. Put these on all cell welds to insulate.
Get Channellock PN 748, which are long reach cutters:
https://www.channellock.com/product.aspx?zpid=407
Start at one end, and SNIP/SNIP/SNIP/SNIP ... Pull cells out bottom.Pop-rivet cells together with .032/.064 thick .375 wide and 1.75" long copper strips on the outside for support. This will pass at least as much current as the 3 small OEM welds.
However... If you are not careful, you could cut the tabs too short. AND you cannot do 3P 1S this way.
http://www.diyelectriccar.com/forums/sh ... tcount=118
Well, with the right tools, you can take out the cells "as welded" in 3P 1S. It is actually easier than taking out the individual cells and safer. Weight per cell is 1153.0g / 3 with the copper tab left on. There is room to separate the plates for air cooling.
Yabert's tests of Volt packs on the DiyEv car forum suggest a high C rate, 15+ C!:
http://www.diyelectriccar.com/forums/sh ... 09698.html
Last edited by
MitchJi on Aug 15 2014 1:15pm, edited 15 times in total.
Best Wishes!
Mitch
Buying a new Tesla? Please consider using our referral code
https://ts.la/lynnem96959 to get one thousand miles of free Supercharging.
The best quality batteries and lowest priced batteries for DIY EV's are tier 1 OEM Quality Cells from salvaged (wrecked) EV packs. Three examples are Chevy Volt and Nissan Leaf and Tesla Model 3 packs.
Nissan Leaf Module specs are here
Chevy Volt Pack Info - Salvage 16kwh Packs Under $2k here
-
MitchJi 1 GW

- Posts: 3151
- Joined: Jun 02 2008 8:09pm
- Location: Marin County California
Post
by MitchJi » Aug 15 2014 10:42am
Last edited by
MitchJi on Sep 06 2015 6:21pm, edited 2 times in total.
Best Wishes!
Mitch
Buying a new Tesla? Please consider using our referral code
https://ts.la/lynnem96959 to get one thousand miles of free Supercharging.
The best quality batteries and lowest priced batteries for DIY EV's are tier 1 OEM Quality Cells from salvaged (wrecked) EV packs. Three examples are Chevy Volt and Nissan Leaf and Tesla Model 3 packs.
Nissan Leaf Module specs are here
Chevy Volt Pack Info - Salvage 16kwh Packs Under $2k here
-
Monstarr 100 W

- Posts: 215
- Joined: Apr 12 2011 4:56am
- Location: The Netherlands
Post
by Monstarr » Aug 15 2014 10:52am
??
what do u mean?
-
MitchJi 1 GW

- Posts: 3151
- Joined: Jun 02 2008 8:09pm
- Location: Marin County California
Post
by MitchJi » Sep 06 2015 6:09pm
bump
Best Wishes!
Mitch
Buying a new Tesla? Please consider using our referral code
https://ts.la/lynnem96959 to get one thousand miles of free Supercharging.
The best quality batteries and lowest priced batteries for DIY EV's are tier 1 OEM Quality Cells from salvaged (wrecked) EV packs. Three examples are Chevy Volt and Nissan Leaf and Tesla Model 3 packs.
Nissan Leaf Module specs are here
Chevy Volt Pack Info - Salvage 16kwh Packs Under $2k here
-
Hillhater 100 GW

- Posts: 10318
- Joined: Aug 03 2010 10:33pm
- Location: Sydney ..(Hilly part !) .. Australia/ Down under !
Post
by Hillhater » Sep 06 2015 11:58pm
MitchJi wrote:bump
.??? Why. .??

This forum owes its existence to Justin of ebikes.ca
-
MitchJi 1 GW

- Posts: 3151
- Joined: Jun 02 2008 8:09pm
- Location: Marin County California
Post
by MitchJi » Sep 07 2015 7:39pm
Hillhater wrote:MitchJi wrote:bump
.??? Why. .??

I posted this purchase information:
Volt packs are easy to find now for $1,500-$2k

. There are about 50 now on car-part.com.
http://www.car-part.com/
I searched by distance from my zip code. I found one for $1,771, with a six month warranty 90 miles away:
Best Wishes!
Mitch
Buying a new Tesla? Please consider using our referral code
https://ts.la/lynnem96959 to get one thousand miles of free Supercharging.
The best quality batteries and lowest priced batteries for DIY EV's are tier 1 OEM Quality Cells from salvaged (wrecked) EV packs. Three examples are Chevy Volt and Nissan Leaf and Tesla Model 3 packs.
Nissan Leaf Module specs are here
Chevy Volt Pack Info - Salvage 16kwh Packs Under $2k here
-
lettersize 10 mW

- Posts: 32
- Joined: Oct 26 2015 9:14am
Post
by lettersize » Oct 26 2015 5:37pm
MitchJi, you've mentioned that cells are welded into 6S and 12S modules making it very difficult to reconfigure the packs.
But can the 48v module be reconfigured to 24v module? The Chevy Volt pack has 2x 24v/45Ah modules and 7x 48v/45Ah modules.
I wonder if i can turn 48v/45Ah module in 24v/90ah module.
-
MitchJi 1 GW

- Posts: 3151
- Joined: Jun 02 2008 8:09pm
- Location: Marin County California
Post
by MitchJi » Oct 30 2015 10:34am
lettersize wrote:MitchJi, you've mentioned that cells are welded into 6S and 12S modules making it very difficult to reconfigure the packs.
But can the 48v module be reconfigured to 24v module? The Chevy Volt pack has 2x 24v/45Ah modules and 7x 48v/45Ah modules.
I wonder if i can turn 48v/45Ah module in 24v/90ah module.
Check the DIY Ev threads in my op.
Best Wishes!
Mitch
Buying a new Tesla? Please consider using our referral code
https://ts.la/lynnem96959 to get one thousand miles of free Supercharging.
The best quality batteries and lowest priced batteries for DIY EV's are tier 1 OEM Quality Cells from salvaged (wrecked) EV packs. Three examples are Chevy Volt and Nissan Leaf and Tesla Model 3 packs.
Nissan Leaf Module specs are here
Chevy Volt Pack Info - Salvage 16kwh Packs Under $2k here
-
baltimorebiker 10 mW

- Posts: 20
- Joined: Feb 24 2015 12:30pm
- Location: Baltimore, USA
Post
by baltimorebiker » Sep 13 2016 5:14pm
Hi Forum People,
I just thought it would be relevant for me to post that I have been using a 2 kwhr 44v chevy volt module paired to a leaf bike 48v 1500w motor. Used tp 1430c charger. I did not use a BMS.It has been rock solid for the last year. Tons of power, tons of capacity. Just really heavy (45 lb battery and 20 lb motor)
I had a top speed of about 42 mph on flat ground using 1800 watts. I was able to go bike from Baltimore to Washington DC without pedaling (I actually can't pedal because I removed the chain) with lots of battery left over.
I'd be willing to answer any questions.
yescom 48V 1000w kit
sunthing 15 ah battery, which tested at 10 ah
1500w leaf bike motor
12s 45 ah 2000 whr chevy volt module
-
Harold in CR 1 MW

- Posts: 1635
- Joined: Feb 01 2010 7:19pm
- Location: Costa Rica
Post
by Harold in CR » Sep 13 2016 6:29pm
I buy these and sell off part of them, so I can afford to get what I need at a decent price, because I can't afford to buy and keep a whole pack.
Actually, getting ready to go to Florida and build some parts and will buy another pack and offer modules for those guys that don't need a complete Volt battery.
I'm presently modding a dirt bike to a leaning reverse tadpole and will install a 28S Volt pack in it, with lots of room for groceries, controllers, charger, etc.
Also, going to convert most of our house to Volt battery, because of terrible Power Co. service and cost per Kwh.
Thanks to Justin, the forum is open source and NON-commercialized.
-
redilast 1 kW

- Posts: 317
- Joined: Apr 14 2016 12:47am
Post
by redilast » Sep 15 2016 4:24am
What kind of BMS and or Chargers are people using with these monster packs? These would be great for off grid energy storage for about the same price as golf cart flooded batteries...
-
mark.curry3 100 W

- Posts: 103
- Joined: Nov 20 2014 2:52pm
- Location: Tampa, fl
Post
by mark.curry3 » Oct 11 2016 3:24pm
These posts about the chevy volt batteries have me thinking about how too use them in my 60V 1000w e-scooter. I found a 88v pack for around $900 and am trying to see if it could be configured to use with my bike. The size may be an issue but I have not been able to find dimensions. i assume they can be installed sideways or upside down like lifepo4. I also need to know if the standard lifepo4 charger would work. If the size is workable, there is a possibility that I could move to a 72v bike if that would work better.. Any guidance would be appreciated,
-
liveforphysics 100 GW

- Posts: 14134
- Joined: Oct 29 2008 1:48am
- Location: Santa Cruz, CA, USA
Post
by liveforphysics » Oct 11 2016 5:46pm
baltimorebiker wrote:Hi Forum People,
I just thought it would be relevant for me to post that I have been using a 2 kwhr 44v chevy volt module paired to a leaf bike 48v 1500w motor. Used tp 1430c charger. I did not use a BMS.It has been rock solid for the last year. Tons of power, tons of capacity. Just really heavy (45 lb battery and 20 lb motor)
I had a top speed of about 42 mph on flat ground using 1800 watts. I was able to go bike from Baltimore to Washington DC without pedaling (I actually can't pedal because I removed the chain) with lots of battery left over.
I'd be willing to answer any questions.
Sounds like a nice capacity/voltage pack. What's the weight?
Each carcinogen vapor exposure includes a dice roll for cancer.
Each mutagen vapor exposure includes a dice roll for reproductive genetic defects in your children.
Each engine start sprays them into a shared atmosphere which includes beings not offered an opportunity to consent accepting these cancer experiences and defective genetics life experiences.
Every post is a free gift to the collective of minds composing the living bleeding edge of LEV development on our spaceship.
-
Monstarr 100 W

- Posts: 215
- Joined: Apr 12 2011 4:56am
- Location: The Netherlands
Post
by Monstarr » Oct 27 2016 7:31am
liveforphysics wrote:baltimorebiker wrote:Hi Forum People,
I just thought it would be relevant for me to post that I have been using a 2 kwhr 44v chevy volt module paired to a leaf bike 48v 1500w motor. Used tp 1430c charger. I did not use a BMS.It has been rock solid for the last year. Tons of power, tons of capacity. Just really heavy (45 lb battery and 20 lb motor)
I had a top speed of about 42 mph on flat ground using 1800 watts. I was able to go bike from Baltimore to Washington DC without pedaling (I actually can't pedal because I removed the chain) with lots of battery left over.
I'd be willing to answer any questions.
Sounds like a nice capacity/voltage pack. What's the weight?

-
Monstarr 100 W

- Posts: 215
- Joined: Apr 12 2011 4:56am
- Location: The Netherlands
Post
by Monstarr » Oct 27 2016 7:46am
baltimorebiker wrote:Hi Forum People,
I just thought it would be relevant for me to post that I have been using a 2 kwhr 44v chevy volt module paired to a leaf bike 48v 1500w motor. Used tp 1430c charger. I did not use a BMS.It has been rock solid for the last year. Tons of power, tons of capacity. Just really heavy (45 lb battery and 20 lb motor)
I had a top speed of about 42 mph on flat ground using 1800 watts. I was able to go bike from Baltimore to Washington DC without pedaling (I actually can't pedal because I removed the chain) with lots of battery left over.
I'd be willing to answer any questions.
I have done the same on a Novox C10 electric moped/scooter with hubmotor. Refitted the 12s3p pack with compression bands from parcel packingband machine I have at my work. I then fully covered it with protective tape and carry it around in a low priced bag I bought from Hobbyking (Turnigy Heavy Duty Large Carry Bag). Fits nicely.

-
eddieboy 1 µW

- Posts: 1
- Joined: Feb 18 2019 5:58pm
Post
by eddieboy » Feb 18 2019 6:06pm
Well, with the right tools, you can take out the cells "as welded" in 3P 1S. It is actually easier than taking out the individual cells and safer. Weight per cell is 1153.0g / 3 with the copper tab left on. There is room to separate the plates for air cooling.
What are the necessary tools to take out the cells "as welded"?
-
MitchJi 1 GW

- Posts: 3151
- Joined: Jun 02 2008 8:09pm
- Location: Marin County California
Post
by MitchJi » Feb 19 2019 5:35pm
eddieboy wrote: ↑Feb 18 2019 6:06pm
Well, with the right tools, you can take out the cells "as welded" in 3P 1S. It is actually easier than taking out the individual cells and safer. Weight per cell is 1153.0g / 3 with the copper tab left on. There is room to separate the plates for air cooling.
What are the necessary tools to take out the cells "as welded"?
I don’t remember how it’s done. Check the article on the diyev forum that i posted the quote from in my op.
At this point in time I’d compare them with Tesla M3 modules. The Tesla M3 packs are starting to be available for excellent prices.
